Webhook Communication

Location

Main Dashboard > Select {Account} > Settings > Communication settings > Update communication settings > Configure 'Webhook'

Trend Micro Cloud One™ – Conformity supports notifications sent via a custom webhook channel. These notifications will be sent to user-created channels with all relevant users receiving the notifications.

  1. Click on Create a Webhook channel.
  2. Set automatic notifications.
  3. Configure Triggers.
  4. Configure now will allow the addition of a Webhook channel using the following parameter


  5. Webhook URL: Make sure that you enter a secure Webhook URL with 'https'

!!! note "" * URL cannot begin with http:// (only https://) * URL cannot contain localhost * URL cannot contain an IP address

  1. Webhook Security Token

!!! note "" Any non-base64 characters will not be accepted

Validating payloads from Conformity If you decide to set the optional security token, Conformity uses it to create a hash signature with each payload.The hash signature is passed along with each request to the url you have specified in the headers as X-Conformity-Signature.

The idea is to compute a hash using your provided security token, and ensuring that the hash from our end matches with your end. The hash signature is generated from Conformity and uses HMAC hexdigest (sha-256) so you could set up your server similar to this example below:


   const signatureHash = request.headers["X-Conformity-Signature"];
   const hmac = crypto.createHmac("sha256", YOUR_SECURITY_TOKEN);
   const digest = Buffer.from(
      hmac.update(JSON.stringify(PAYLOAD_BODY)).digest("hex")
   );
   const checksum = Buffer.from(signatureHash, "utf8");
   if (
      checksum.length !== digest.length ||
      !crypto.timingSafeEqual(digest, checksum)
   ) {
      console.log('Request body digest(${ digest }) did not match X - Conformity - Signature(${ checksum })');
      throw new Error("Hashes do not match!");
   }
   console.log("Hashes match!");
  1. Copy communication settings

Once the channel creation is successful, you will be able to see the Webhook channel from your Communication Settings.
